Butterfly Valve Water Type Centre Disc
Material of Construction
| NO. | Description | Material | Qty. |
|---|---|---|---|
| 1 | Body | C.I / WCB / S.G.I / CF8 / CF8M | 1 |
| 2 | Disc | C.I / WCB / S.G.I / CF8 / CF8M / AB - 2 | 1 |
| 3 | Shaft | SS 410 / SS 304 / SS316 / MINEL | 1 / 2 |
| 4 | Seat | NITRIL / EPDM / SILICONE / VITIOM / HYPLON | 1 |
| 5 | " O " Ring | NITRIL / EPDM / SILICONE / VITIOM / HYPLON | 2 |
| 6 | Scale Plate | M.S. FEBRICATED | 1 |
| 7 | Flow Control Level | M.S. FEBRICATED | 1 |
| 8 | Brg. Bush | G.M. / BRONGE / POLYACETEL / PTFE / GF - PTFE / G.F.T / SS 304 / 316 | 2 |
Dimensions
| Size | F to F | OD |
|---|---|---|
| 1.1/2" | 33 | 85 |
| 2" | 43 | 91 |
| 2.1/2" | 46 | 111 |
| 3" | 46 | 124 |
| 4" | 52 | 162 |
| 5" | 56 | 190 |
| 6" | 56 | 219 |
| 8" | 60 | 273 |
| 10" | 68 | 337 |
| 12" | 78 | 384 |
